| Nombor Bahagian | B156XTN07.0 HWKA |
| Jenama | AUO |
| Saiz | 15.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | AUO |
| model panel | B156XTN07.0 HWKA |
| saiz panel | 15.6" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 100PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 344.232(W)×193.536(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 359.5(W)×223.8(H) mm |
| permukaan | - |
| kecerahan | - |
| nisbah kontras | 500:1 (Typ.) (TM) |
| sudut pandangan | 45/45/15/35 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 6 o'clock |
| masa tindak balas | 8 (Typ.)(Tr+Td) |
| warna paparan | 262K |
| jenis lampu | WLED |
| kekerapan | - |
| skrin sentuh | Without |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| permohonan | Laptop |
| antara muka isyarat | eDP (1 Lane) , 30 pins Connector |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
