| Nombor Bahagian | B116XAK01.0 |
| Jenama | AUO |
| Saiz | 11.6 |
| Permohonan | Laptop |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | |
| jenama | AUO |
| model | B116XAK01.0 (AUO405C) |
| saiz pepenjuru | 11.6 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1366(RGB)×768 [WXGA] 135PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 256.125(H)×144(V) mm |
| garis besar malap. | 278(H)×168.02(V) ×3.2(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 27 (Typ.)(Tr+Tf) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | AHVA, Normally Black, Transmissive |
| warna sokongan | 262K 50% NTSC |
| sumber cahaya | WLED , 15K hours , With LED Driver |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| direka untuk | Laptop |
| kadar bingkai | 60Hz |
| panel sentuh | On-Cell Touch |
| Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
