| Nombor Bahagian | AV103Z7M-N13-3850 |
| Jenama | BOE |
| Saiz | 10.3 |
| Permohonan | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 9S3P |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | AV103Z7M-N13-3850 |
| saiz panel | 10.3" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×720, 200PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 243.648(W)×91.368(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 256.748(W)×107.068(H) ×10.5(D) mm |
| permukaan | - |
| kecerahan | 850 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | HADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| warna paparan | 16.7M 75% NTSC |
| jenis lampu | 9S3P WLED , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Automotive Display |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 50 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C |
