| Nombor Bahagian | AT070WSM-NW2 |
| Jenama | BOE |
| Saiz | 7.0 |
| Permohonan | Automotive Display |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | BOE |
| model | AT070WSM-NW2 |
| saiz pepenjuru | 7.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 170PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 154.214(H)×85.92(V) mm |
| garis besar malap. | - |
| kecerahan | - |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 25 (Typ.)(Tr+Tf) |
| sudut pandangan | 80/80/60/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M 50% NTSC |
| sumber cahaya | WLED |
| berat badan | - |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
