| Nombor Bahagian | AT070MP11 |
| Jenama | Mitsubishi |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | Mitsubishi |
| nama model | AT070MP11 |
| saiz skrin | 7.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 133PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| garis besar (mm) | 169.8 × 109.7 × 9.4 (H×V×D) |
| kawasan bezel (mm) | 154.4 × 93.5 (H×V) |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 1300 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 4/12 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | SWV, Normally Black, Transmissive |
| kedalaman warna | 262K/16.7M 50% NTSC |
| lampu latar | WLED , 100K hours , No Driver |
| jisim | 200g |
| digunakan untuk | Industrial Outdoor High Brightness Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
