| Nombor Bahagian | AMS596DU08-0 |
| Jenama | SAMSUNG |
| Saiz | 6.0 |
| Permohonan | Mobile Phone |
| Resolusi | 1440×2560 |
| Komposisi | AM-OLED, Assembly |
| Kecerahan | |
| CR | 10000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | MIPI |
| jenama | SAMSUNG |
| model | AMS596DU08-0 |
| saiz pepenjuru | 6.0 inch |
| menaip | AM-OLED, Assembly |
| format piksel | 1440(RG/BG)×2560 [Quad-HD] 402PPI |
| konfigurasi | RG/BG PenTile |
| kawasan aktif | 74.16(H)×131.84(V) mm |
| garis besar malap. | 81.26(H)×151.4(V) mm |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 10000:1 (Min.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | 88/88/88/88 (Min.)(CR≥10) |
| mod operasi | - |
| warna sokongan | 16.7M 100% NTSC |
| sumber cahaya | self |
| berat badan | - |
| direka untuk | Mobile Phone |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| jenis antara muka | MIPI (2 ch, 4 data lanes) , 60 pins Connector |
| bekalan kuasa | 1.8/3.1/4.0V (Typ.)(IOVDD/VCI/VBAT) |
| persekitaran | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| A060SE02 V7 | AUO | 6.0 | 800×600 |
| ED060SC1 | E Ink | 6.0 | 800×600 |
| ED060SC7 | E Ink | 6.0 | 600×800 |
| ED060SC9 | E Ink | 6.0 | 600×800 |
| ED060SCE | E Ink | 6.0 | 600×800 |
| HSD060FMW1-C00 | HannStar | 6.0 | 540×960 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LQ060B3DW01 | SHARP | 6.0 | 768×128 |
| LS060S2UD01 | SHARP | 6.0 | 600×800 |
| TM060SDH01 | Tianma | 6.0 | 800×600 |
