| Nombor Bahagian | AMS258DN01 |
| Jenama | SAMSUNG |
| Saiz | 2.6 |
| Permohonan | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | OLED, AM-OLED |
| Kecerahan | |
| CR | |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | 8-bit |
| pengilang | SAMSUNG |
| nama model | AMS258DN01 |
| saiz skrin | 2.6 inch |
| jenis skrin | OLED, AM-OLED |
| nombor piksel | 240(RGB)×320 (QVGA) 154PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 39.6 × 52.48 (H×V) |
| garis besar (mm) | 44.48 × 62.35 (H×V×D) |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | 16.7M |
| lampu latar | self |
| jisim | TBD |
| digunakan untuk | Mobile Phone |
| kadar segar semula | - |
| skrin sentuh | Without |
| jenis isyarat | 8-bit 8080 parallel , Connector 24 pins |
| bekalan voltan | 1.65/2.8/4.6/-5.0V (Typ.)(VDDIO/VPNL/ELVDD/ELVSS) |
| maks. penilaian | Storage Temp.: -40 ~ 80 °C Operating Temp.: -30 ~ 70 °C |
