| Nombor Bahagian | AM-800480R2TMQW-U0H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 250:1 |
| Warna | 65K |
| Lampu latar | WLED |
| Antara muka | UART |
| pengilang | AMPIRE |
| nama model | AM-800480R2TMQW-U0H |
| saiz skrin | 7.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 133PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| garis besar (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| kawasan bezel (mm) | 155.3 × 94.3 (H×V) |
| rawatan | - |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 250 : 1 (Typ.) (TM) |
| sudut pandangan | 70/70/60/60 (Typ.)(CR≥10) |
| tindak balas | 50 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 65K 48% NTSC |
| lampu latar | WLED , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | - |
| skrin sentuh | Without |
| jenis isyarat | UART , 8 pins Connector |
| bekalan voltan | 4.6/26.0V (Min./Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
