| Nombor Bahagian | AM-800480N3TZQW-57H |
| Jenama | AMPIRE |
| Saiz | 5.0 |
| Permohonan | Industrial Automotiv |
| Resolusi | 800×480 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 3S6P |
| Antara muka | |
| pengilang | AMPIRE |
| nama model | AM-800480N3TZQW-57H |
| saiz skrin | 5.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 188PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 108 × 64.8 (H×V) |
| garis besar (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| kawasan bezel (mm) | 109.6 × 66.4 (H×V) |
| rawatan | - |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 262K |
| lampu latar | 3S6P WLED , 50K hours , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
