| Nombor Bahagian | AM-800480LATMQW-TN0H-L |
| Jenama | AMPIRE |
| Saiz | 5.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 250:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | AMPIRE |
| saiz pepenjuru | 5.0 inch |
| format piksel | 800(RGB)×480 [WVGA] 188PPI |
| kawasan aktif | 108(H)×64.8(V) mm |
| kecerahan | 360 cd/m² (Typ.) |
| arah pandang | - |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 52% NTSC |
| berat badan | - |
| kadar bingkai | 60Hz |
| jenis antara muka | Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | AM-800480LATMQW-TN0H-L |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 118.5(H)×74(V) ×5.16(D) mm |
| nisbah kontras | 250:1 (Typ.) (TM) |
| masa tindak balas | 15/35 (Max.)(Tr/Td) |
| mod operasi | TN, Normally White, Transflective |
| sumber cahaya | WLED [3S6P] , W/O Driver |
| direka untuk | Industrial |
| panel sentuh | PCAP |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| L5F30705T10 | Epson | 5.0 | 400×240 |
| LH500X01-SD01 | LG Display | 5.0 | 768×1024 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| M050SWN1 R2 | IVO | 5.0 | 480×234 |
| P50AD2 | E Ink | 5.0 | 320×234 |
