| Nombor Bahagian | AM-800480L1TMQW-TN0H |
| Jenama | AMPIRE |
| Saiz | 5.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 250:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | AMPIRE |
| model | AM-800480L1TMQW-TN0H |
| saiz pepenjuru | 5.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 188PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 108(H)×64.8(V) mm |
| garis besar malap. | 118.5(H)×77.1(V) ×6.66(D) mm |
| kawasan bezel | 110.6(H)×67.4(V) mm |
| rawatan | Antiglare |
| kecerahan | 360 cd/m² (Typ.) |
| nisbah kontras | 250:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 15/35 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 16.7M 52% NTSC |
| sumber cahaya | WLED [3S6P] , W/O Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| jenis antara muka | Parallel RGB (1 ch, 8-bit) , 45 pins FPC |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
