| Nombor Bahagian | AM-800480D1TMQW-00H |
| Jenama | AMPIRE |
| Saiz | 8.0 |
| Permohonan | Industrial Automotiv |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | AMPIRE |
| model | AM-800480D1TMQW-00H |
| saiz pepenjuru | 8.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 116PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 176.64(H)×99.36(V) mm |
| garis besar malap. | 192.8(H)×116.9(V) ×6.7(D) mm |
| kawasan bezel | 180.1(H)×103.4(V) mm |
| rawatan | Antiglare |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M |
| sumber cahaya | WLED , 20K hours , W/O Driver |
| berat badan | 251g (Typ.) |
| direka untuk | Industrial Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
