| Nombor Bahagian | AM-800480CTZQW-A5H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | 6S5P |
| Antara muka | LVDS |
| pengilang | AMPIRE |
| nama model | AM-800480CTZQW-A5H |
| saiz skrin | 7.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 800(RGB)×480 (WVGA) 133PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| garis besar (mm) | 165 × 104.4 × 11.61 (H×V×D) |
| kawasan bezel (mm) | 15.48 × 93.85 (H×V) |
| rawatan | - |
| kecerahan | 1500 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 262K 58% NTSC |
| lampu latar | 6S5P WLED , 50K hours , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial Outdoor High Brightness |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (1 ch, 6-bit) , 20 pins Connector |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
