| Nombor Bahagian | AM-800480BDTZQW-00H |
| Jenama | AMPIRE |
| Saiz | 4.3 |
| Permohonan | Industrial Automotiv |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | AMPIRE |
| model | AM-800480BDTZQW-00H |
| saiz pepenjuru | 4.3 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 216PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 95.04(H)×53.856(V) mm |
| garis besar malap. | 105.3(H)×67(V) mm |
| kawasan bezel | 97.9(H)×56.7(V) mm |
| rawatan | - |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 40 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | Normally Black, Transmissive |
| warna sokongan | 16.2M |
| sumber cahaya | WLED [6S2P] , 50K hours , W/O Driver |
| berat badan | - |
| direka untuk | Industrial Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
