| Nombor Bahagian | AM-800480AZTMQW-50H |
| Jenama | AMPIRE |
| Saiz | 5.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 3S6P |
| Antara muka | |
| jenama panel | AMPIRE |
| saiz panel | 5.0" |
| resolusi | 800(RGB)×480, WVGA, 188PPI |
| kawasan paparan | 108(W)×64.8(H) mm |
| saiz garis besar | 119.7(W)×78(H) ×6.1(D) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandangan | 75/75/70/60 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 16.7M 47% NTSC |
| kekerapan | 60Hz |
| berat badan | - |
| model panel | AM-800480AZTMQW-50H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Antiglare |
| nisbah kontras | 600:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 2/6 (Typ.)(Tr/Td) |
| jenis lampu | 3S6P WLED , 50K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
