| Nombor Bahagian | AM-480272HBTMQW-T00H |
| Jenama | AMPIRE |
| Saiz | 4.3 |
| Permohonan | Industrial |
| Resolusi | 480×272 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 250:1 |
| Warna | 16.7M |
| Lampu latar | 7S1P |
| Antara muka | Parallel |
| pengilang | AMPIRE |
| nama model | AM-480272HBTMQW-T00H |
| saiz skrin | 4.3 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 480(RGB)×272 (WQVGA) 128PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 95.04 × 53.856 (H×V) |
| garis besar (mm) | 105.5 × 67.2 × 7.99 (H×V×D) |
| kawasan bezel (mm) | 98.7 × 57.5 (H×V) |
| rawatan | - |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 250 : 1 (Typ.) (TM) |
| sudut pandangan | 65/65/45/45 (Typ.)(CR≥10) |
| tindak balas | 40 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | 6 o'clock |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M |
| lampu latar | 7S1P WLED , 20K hours , No Driver |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | PCAP |
| jenis isyarat | Parallel RGB (1 ch, 8-bit) , FPC 54 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AMS429QC08 | Samsung | 4.3 | 540×960 |
| AT043TN24 V.7 | Innolux | 4.3 | 480×272 |
| BT043NHME601 | BOE | 4.3 | 360×600 |
| LQ043T1DH01 | SHARP | 4.3 | 480×272 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LT043MDY5000 | TOSHIBA | 4.3 | 720×1280 |
| TD043MTEA2 | TPO | 4.3 | 800×480 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
