| Nombor Bahagian | AM-19201200CTZQW-T01 |
| Jenama | AMPIRE |
| Saiz | 10.1 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | AMPIRE |
| model | AM-19201200CTZQW-T01 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×1200 [WUXGA] 225PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 216.576(H)×135.36(V) mm |
| garis besar malap. | 244.8(H)×155.3(V) ×8.01(D) mm |
| kecerahan | 850 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | AHVA, Normally Black, Transmissive |
| warna sokongan | 16.7M 49% NTSC |
| sumber cahaya | WLED [7S6P] , 50K hours , W/O Driver |
| berat badan | - |
| direka untuk | Industrial Outdoor High Brightness |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| F101NWN7-0 | IVO | 10.1 | 1920×1200 |
| G101AGE-L01 | Innolux | 10.1 | 800×600 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| N101L6-L0D | Innolux | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
