| Nombor Bahagian | AM-1280800J4TZQW-T00 |
| Jenama | AMPIRE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM-1280800J4TZQW-T00 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 216.96(H)×135.6(V) mm |
| garis besar malap. | 231(H)×150(V) ×8.8(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | Normally Black, Transmissive |
| warna sokongan | 16.7M |
| sumber cahaya | WLED [3S11P] , 15K hours , With LED Driver |
| berat badan | TBD |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| jenis antara muka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
