| Nombor Bahagian | AM-1024768Y2TZQW-A1H |
| Jenama | AMPIRE |
| Saiz | 10.4 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AMPIRE |
| model panel | AM-1024768Y2TZQW-A1H |
| saiz panel | 10.4" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 123PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 211.2(W)×158.4(H) mm |
| pembukaan bezel | 213.2(W)×160.4(H) mm |
| saiz garis besar | 236(W)×174.3(H) ×10.4(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | IPS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| warna paparan | 16.2M |
| jenis lampu | WLED , 30K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | TBD |
| permohonan | Industrial Outdoor High Brightness |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
