| Nombor Bahagian | AM-1024768R3TNQW-T00H |
| Jenama | AMPIRE |
| Saiz | 12.1 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | AMPIRE |
| model | AM-1024768R3TNQW-T00H |
| saiz pepenjuru | 12.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 105PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 245.76(H)×184.32(V) mm |
| garis besar malap. | 279(H)×209(V) ×11.2(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
