| Nombor Bahagian | AM-1024768FCTMQW-T00H |
| Jenama | AMPIRE |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM-1024768FCTMQW-T00H |
| saiz pepenjuru | 10.4 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 123PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 210.4(H)×157.8(V) mm |
| garis besar malap. | 238.6(H)×175.8(V) mm |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 14/11 (Typ.)(Tr/Td) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10) |
| mod operasi | Normally Black, Transmissive |
| warna sokongan | 262K/16.2M 57% NTSC |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
