| Nombor Bahagian | AM-1024600K7TMQW-T53H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.7M |
| Lampu latar | 5S3P |
| Antara muka | LVDS |
| jenama panel | AMPIRE |
| saiz panel | 7.0" |
| resolusi | 1024(RGB)×600, WSVGA, 169PPI |
| kawasan paparan | 153.6(W)×90(H) mm |
| saiz garis besar | 165.5(W)×104.44(H) ×11.93(D) mm |
| kecerahan | 425 cd/m² (Typ.) |
| sudut pandangan | 75/75/70/75 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K/16.7M |
| kekerapan | 60Hz |
| berat panel | TBD |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | AM-1024600K7TMQW-T53H |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | - |
| nisbah kontras | 700:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 20/20 (Typ.)(Tr/Td) |
| jenis lampu | 5S3P WLED , 50K hours , With LED Driver |
| skrin sentuh | PCAP |
| permohonan | Industrial |
