| Nombor Bahagian | AC121SA04 |
| Jenama | Mitsubishi |
| Saiz | 12.1 |
| Permohonan | Industrial |
| Resolusi | 800×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | Mitsubishi |
| model | AC121SA04 |
| saiz pepenjuru | 12.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×600 [SVGA] 82PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 246(H)×184.5(V) mm |
| garis besar malap. | 260.5(H)×203(V) ×10(D) mm |
| kawasan bezel | 249.0(H)×187.5(V) mm |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/60/80 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M 72% NTSC |
| sumber cahaya | WLED , 70K hours , With LED Driver |
| berat badan | 580g (Typ.) |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
