| Nombor Bahagian | AA104XN01 |
| Jenama | Mitsubishi |
| Saiz | 10.4 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1024×768 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | Mitsubishi |
| nama model | AA104XN01 |
| saiz skrin | 10.4 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1024(RGB)×768 (XGA) 123PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 211.2 × 158.4 (H×V) |
| garis besar (mm) | 230 × 180.2 (H×V×D) |
| kecerahan | 1300 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10) |
| tindak balas | - |
| pandangan yang baik di | Symmetry |
| mod kerja | SWV, Normally Black |
| kedalaman warna | 262K/16.7M 70% NTSC |
| lampu latar | WLED , 100K hours , With LED Driver |
| jisim | - |
| digunakan untuk | Industrial Outdoor High Brightness |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (1 ch, 6/8-bit) |
| maks. penilaian | Storage Temp.: -40 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 6.8G (66.64 m/s²) |
