| Nombor Bahagian | AA070TA01 |
| Jenama | Mitsubishi |
| Saiz | 7.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1280×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | Mitsubishi |
| saiz panel | 7.0" |
| resolusi | 1280(RGB)×768, WXGA, 214PPI |
| kawasan paparan | 151.68(W)×91.01(H) mm |
| saiz garis besar | 169.8(W)×109.7(H) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| sudut pandangan | 88/88/88/88 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 262K/16.7M 49% NTSC |
| kekerapan | 60Hz |
| berat badan | 200g (Typ.) |
| model panel | AA070TA01 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 155.1(W)×94.4(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | SWV, Normally Black, Transmissive |
| masa tindak balas | 12/12 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 100K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial Outdoor High Brightness Automotive Display |
