| Nombor Bahagian | A050FTT04.0 |
| Jenama | AUO |
| Saiz | 5.0 |
| Permohonan | Portable Navigation |
| Resolusi | 480×272 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | AUO |
| saiz pepenjuru | 5.0 inch |
| format piksel | 480(RGB)×272 [WQVGA] 109PPI |
| kawasan aktif | 110.88(H)×62.832(V) mm |
| kawasan bezel | - |
| kecerahan | 400 cd/m² (Typ.) |
| arah pandang | 6 o'clock |
| sudut pandangan | 70/70/40/60 (Typ.)(CR≥10) |
| warna sokongan | 262K 50% NTSC |
| berat badan | 75g |
| kadar bingkai | - |
| jenis antara muka | Parallel RGB (1 ch, 6-bit) + SPI , 67 pins FPC |
| bekalan kuasa | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | A050FTT04.0 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 120.73(H)×75.83(V) ×4.47(D) mm |
| rawatan | Hard coating (3H) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| masa tindak balas | 7/23 (Typ.)(Tr/Td) |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED [6S2P] , 10K hours , W/O Driver |
| direka untuk | Portable Navigation MP3 PMP |
| panel sentuh | 4-wire Resistive Touch |
