| Nombor Bahagian | 990001260 |
| Jenama | Chimei Innolux |
| Saiz | 2.7 |
| Permohonan | Digital Still Camera |
| Resolusi | 960×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | Chimei Innolux |
| model | 990001260 |
| saiz pepenjuru | 2.7 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 960×480 [HVGA] 217PPI |
| konfigurasi | RGB Delta |
| kawasan aktif | 54(H)×40.512(V) mm |
| garis besar malap. | 63.7(H)×46.6(V) ×2.2(D) mm |
| kawasan bezel | - |
| rawatan | Hard coating |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 60/60/50/55 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 16.7M |
| sumber cahaya | WLED [5S1P] , W/O Driver |
| berat badan | TBD |
| direka untuk | Digital Still Camera Digital Video Camera |
| kadar bingkai | - |
| panel sentuh | Without |
| Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -30 ~ 80 °C |
| 990000006 | TPO | 3.0 | 320×240 |
| 990000270 | TPO | 2.5 | 320×240 |
| 990000475 | TPO | 4.3 | 800×480 |
| 990000475P | TPO | 4.3 | 800×480 |
| 990000553 | TPO | 3.5 | 320×240 |
| 990000738 | TPO | 3.5 | 320×240 |
| 990000738A | Innolux | 3.5 | 320×240 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| 990001086 | Innolux | 3.0 | |
| UG-2864ASGIG01 | WiseChip | 2.7 | 128×64 |
