| Nombor Bahagian | 700817 |
| Jenama | Plastic Logic |
| Saiz | 1.38 |
| Permohonan | Wearable Electronic |
| Resolusi | 180×100 |
| Komposisi | EPD, EPD |
| Kecerahan | |
| CR | 10:1 |
| Warna | Grayscale |
| Lampu latar | No |
| Antara muka | 4-wire |
| jenama panel | Plastic Logic |
| model panel | 700817 |
| saiz panel | 1.38" |
| jenis panel | EPD, EPD |
| resolusi | 180×100, 149PPI |
| format piksel | Rectangle |
| kawasan paparan | 30.6(W)×17(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 41.55(W)×23(H) ×0.53(D) mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | - |
| nisbah kontras | 10:1 (Typ.) (RF) |
| sudut pandangan | - |
| mod paparan | - |
| pandangan terbaik pada | - |
| masa tindak balas | 900 (Max.)(4 gray-level) |
| warna paparan | Grayscale |
| jenis lampu | No B/L |
| kekerapan | - |
| skrin sentuh | Without |
| berat panel | 1.50g (Typ.) |
| permohonan | Wearable Electronic Price Tag |
| antara muka isyarat | 4-wire SPI , 26 pins FPC |
| persekitaran | Operating Temp.: 0 ~ 40 °C ; Storage Temp.: -25 ~ 50 °C |
